02250126-352
Air Compressor Filter Elements replacement element
Elementi filtranti del compressore d'aria
Part number 02250126-352 is the air/oil separator core for twin-screw air compressors (commonly used on models such as the LS32). Its main function is to efficiently separate lubricating oil from…
Supply TypeIndependent aftermarket replacement
AvailabilityDisponibile
Tempi di consegna2–3 business days
Riferimento incrociatoTo be confirmedNo cross reference has been added
Reference price · tax included
Request quotation
Orders are confirmed by our team for price, compatibility and delivery.
Flexible DeliveryService Point Pickup
Verified specifications for confident selection.
Confirm installation requirements against the equipment manual or original documentation.
| Altezza | 914mm |
|---|---|
| filtration precision | ≤ 0.01μm |
| Initial pressure drop | ≤ 0.02 MPa |
| diameter | 610mm |
| Peso | 20.4 kg |
Dimensions are indicative, not an engineering drawing.
Part number 02250126-352 is the air/oil separator core for twin-screw air compressors (commonly used on models such as the LS32). Its main function is to efficiently separate lubricating oil from compressed air, reduce the oil content in exhaust air, ensure the quality of compressed air, and protect downstream equipment including filters and dryers.
High-precision Separation: Imported microfiber glass wool is adopted, with an oil-gas separation efficiency of up to 99.99%, which strictly controls the oil content in exhaust gas below 3 ppm.
• Energy Saving and Low Resistance: The advanced Z-type pleated structure provides an ultra-large filtration area while maintaining an extremely low operating pressure drop, greatly reducing the energy consumption of the air compressor.
• Extra-long Service Life: Featuring a robust internal and external metal frame design, it delivers excellent pressure difference resistance and high-temperature resistance. Its service life can reach 4000 to 8000 hours under standard working conditions.
• Safe and Explosion-proof: Equipped with a flange electrostatic grounding conductive structure, it effectively eliminates static electricity generated by high-speed airflow to guarantee production safety at industrial sites.
Installation Notes
Electrostatic Grounding (Extremely Critical): Due to the large volume of this oil separator element, high-velocity airflow will generate strong static electricity. During installation, it must be ensured that the conductive copper sheet/metal pin on the flange gasket maintains good metal contact with the oil-gas tank body. Otherwise, static sparks may easily ignite the internal oil gas and cause an oil tank explosion. 2. Seal Inspection: It is recommended to replace the matching flange gasket at the same time during replacement. 3. Return Oil Pipe Length: Check the oil return check valve and return oil pipe during installation. The return oil pipe must extend exactly to a position 1–2 mm above the center of the inner bottom tray of the oil separator element. An excessively long pipe will break the filter element, while an excessively short pipe cannot siphon the accumulated oil at the bottom, resulting in oil carryover in exhaust air.
Maintenance & Replacement
Replace according to pressure drop or the maintenance schedule. Inspect for leakage and seal damage.
Before Ordering
Confirm medium, flow rate, pressure, temperature, connection and available installation space.
Delivery Options
Shipping or service point pickup. Our team confirms the best arrangement based on destination, weight and lead time.
Confirmed Before Dispatch
After inquiry, we verify specifications, price and supply status before delivery.
Ongoing Support
For specification, installation or quality questions, keep the product and order information available when contacting us.
INQUIRYSend an inquiry for this product
Send your requirements for 02250126-352 and our selection team will confirm compatibility, price and lead time.
Domande frequenti
How do I confirm compatibility without a third-party brand reference?
Provide the product number, dimensions, connection details, operating conditions and equipment information. Our team will confirm the application.
Which dimensions should I measure?
Measure the overall height, outer diameter, inner diameter and thread or connection size. A photo or drawing helps confirm the replacement.
How do I choose the correct seal material?
Seal selection depends on the filtration media, operating temperature and chemical compatibility. We can confirm suitable options for your application.
Can you provide a product data sheet?
Yes. Send the product number and required specifications and we will provide the available data sheet and selection support.
