39712070
Air Compressor Filter Elements replacement element
Elementi filtranti del compressore d'aria
39712070 is an extremely critical oil-gas separator filter element for Ingersoll Rand oil-injected screw air compressors.Core Functions and Values1.Coalescing Separation: Using the physical…
Supply TypeIndependent aftermarket replacement
AvailabilityDisponibile
Tempi di consegna2–3 business days
Riferimento incrociato39823018OEM or cross-reference number
Reference price · tax included
Request quotation
Orders are confirmed by our team for price, compatibility and delivery.
Flexible DeliveryService Point Pickup
Verified specifications for confident selection.
Confirm installation requirements against the equipment manual or original documentation.
| OEM / Cross Reference | 39823018,22402473,36711463 |
|---|---|
| Filtration precision | 0.3μm |
| Diametro esterno | 377 mm |
| inner diameter | 314 mm |
| Altezza | 810 mm |
| Peso | 9.07 kg |
| Initial Pressure Drop | ≤ 0.2 bar |
| Temperatura operativa | 120°C |
Dimensions are indicative, not an engineering drawing.
39712070 is an extremely critical oil-gas separator filter element for Ingersoll Rand oil-injected screw air compressors.
Core Functions and Values
1.Coalescing Separation: Using the physical principle of coalescing, mist-like oil droplets in the air stream are captured and merged, then settle to the bottom of the filter element under gravity, and finally drained back into the system for recycling via the oil return pipe.
2.Protection of Downstream Equipment: It greatly reduces the oil carryover in exhaust gas and effectively extends the service life of downstream precision filters, adsorption/refrigerated dryers and pneumatic terminal equipment.
3.Energy Efficiency Improvement: It maintains an extremely low initial pressure difference, preventing the false rise of air compressor exhaust pressure caused by filter element clogging, thereby cutting energy consumption.
Installation Notes
Stop the system and release pressure before removal. Confirm flow direction and sealing surfaces before installation.
Maintenance & Replacement
1.Recommended replacement cycle: Typically 4,000 hours or 1 year, whichever comes first. The actual service life is significantly affected by the air intake environment (dust, humidity, air pollution) and the quality of the air compressor lubricating oil. 2.Replacement signals: ◦ Obvious oil smell starts to appear in the air at the exhaust port, or the oil consumption of the system increases abnormally. ◦ The pressure drop across the filter element reaches the alarm value (usually around 0.8 to 1.0 bar). 3.Synchronization maintenance recommendation: When replacing the oil-gas separation element each time, it is strongly recommended to replace the air filter element and oil filter element synchronously, and completely replace the lubricating oil of the air compressor to ensure the cleanliness of the entire air system.
Before Ordering
Confirm medium, flow rate, pressure, temperature, connection and available installation space.
Riferimento incrociato
Reference information associated with this product. Contact us if you need help confirming a cross-reference number.
Reference 0139823018OEM / Cross Reference
Reference 0222402473OEM / Cross Reference
Reference 0336711463OEM / Cross Reference
Delivery Options
Shipping or service point pickup. Our team confirms the best arrangement based on destination, weight and lead time.
Confirmed Before Dispatch
After inquiry, we verify specifications, price and supply status before delivery.
Ongoing Support
For specification, installation or quality questions, keep the product and order information available when contacting us.
INQUIRYSend an inquiry for this product
Send your requirements for 39712070 and our selection team will confirm compatibility, price and lead time.
Domande frequenti
How do I confirm compatibility without a third-party brand reference?
Provide the product number, dimensions, connection details, operating conditions and equipment information. Our team will confirm the application.
Which dimensions should I measure?
Measure the overall height, outer diameter, inner diameter and thread or connection size. A photo or drawing helps confirm the replacement.
How do I choose the correct seal material?
Seal selection depends on the filtration media, operating temperature and chemical compatibility. We can confirm suitable options for your application.
Can you provide a product data sheet?
Yes. Send the product number and required specifications and we will provide the available data sheet and selection support.
